Caracteristici generale
Tip Switch
Retea RJ45
Retea Fibra Optica
Numar Porturi
48x RJ45
4x SFP+ (uplink)
Viteza Transfer LAN
10/100/1000/10000 Mbps
Tehnologie de cablare
RJ45 Base-T
Standarde
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6
Securitate
128-bit AES, 256-bit AES
Rutare IP
IPv4: 32000
IPv6: 16000
Caracteristici speciale
Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Cisco StackWise-320 technology
Metoda forwarding
291.66 Mpps
529.76 Mpps (cu stacking)
Switch capacity
392 Gbps
712 Gbps (cu stacking)
Protocoale de rutare
OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG
Tensiune de intrare
100 - 230 VAC, 50/60 Hz
Alimentare
Sursa interna 1100W
Dimensiuni
445 x 44 x 409 mm
